| 型号 | 瓦数 | 电压 | 电流(MA) | 光通量(LM) | 灯头型号 | 显色指数 | 色温(K) | A（mm） | B(min) (mm) | B(max)(mm) | C(mm) | 直径mm） | |
| TL5-MINI | 4 | 29 | 170 | 150/130 | G5 | ≧82 | 2700-6500 | 135.9 | 140.6 | 143 | 150.1 | 16 | |
| 6 | 42 | 160 | 300/260 | G5 | ≧82 | 2700-6500 | 212.1 | 216.8 | 219.2 | 226.3 | 16 | ||
| 8 | 56 | 145 | 450/400 | G5 | ≧82 | 2700-6500 | 288.3 | 293 | 295.4 | 302.5 | 16 | ||
| 13 | 95 | 165 | 950/900 | G5 | ≧82 | 2700-6500 | 517 | 521.6 | 524 | 531.5 | 16 | ||
| 25℃ | 35℃ | ||||||||||||
| TL5-HE | 14 | 100 | 170 | 1250/1150 | 1350/1250 | G5 | ≧82 | 2700-6500 | 549 | 553.7 | 556.1 | 563.2 | 16 |
| 16 | 110 | 170 | 1440/1360 | 1540/1460 | G5 | ≧82 | 2700-6500 | 589.8 | 608.2 | 610.3 | 617.4 | 16 | |
| 21 | 123 | 170 | 2100/1900 | 2250/2050 | G5 | ≧82 | 2700-6500 | 849 | 853.7 | 856.1 | 863.2 | 16 | |
| 28 | 167 | 170 | 2600/2400 | 2900/2700 | G5 | ≧82 | 2700-6500 | 1149 | 1153.7 | 1156.1 | 1163.2 | 16 | |
| 32 | 195 | 170 | 1750/1650 | 2000/1900 | G5 | ≧82 | 2700-6500 | 1199.4 | 1204.7 | 1206.5 | 1213.6 | 16 | |
| 35 | 209 | 170 | 3300/3100 | 3650/3400 | G5 | ≧82 | 2700-6500 | 1449 | 1453.7 | 1456.1 | 1463.2 | 16 | |
| TL5-HO | 24 | 75 | 300 | 1750/1650 | 2000/1900 | G5 | ≧82 | 2700-6500 | 549 | 553.7 | 556.1 | 563.2 | 16 |
| 39 | 112 | 340 | 3100/2950 | 3500/3300 | G5 | ≧82 | 2700-6500 | 849 | 853.7 | 856.1 | 863.2 | 16 | |
| 49 | 191 | 250 | 4500/4300 | 5100/4750 | G5 | ≧82 | 2700-6500 | 1449 | 1453.7 | 1456.1 | 1463.2 | 16 | |
| 54 | 118 | 460 | 5100/4650 | 5400/4950 | G5 | ≧82 | 2700-6500 | 1149 | 1153.7 | 1156.1 | 1163.2 | 16 | |
| 80 | 145 | 555 | 6250/5900 | 7000/6650 | G5 | ≧82 | 2700-6500 | 1449 | 1453.7 | 1456.1 | 1463.2 | 16 | |
